Features
- Disc Capacity 1
- Playback Formats SA-CD(Stereo), CD, CD-R/RW(CD-DA)
- HDAM HDAM-SA2
- Current Feedback Analog Stage Yes
- Power Transformer Very Large Capacity Toroidal w/ Copper Shielded Case
- Zero-Impedance Plate Yes
- Double Layerd Bottom Plates Yes
- Audio DAC NPC SM5866AS Monaural DAC x2
- Display On/Off Yes
- Selectable Filters Yes
- SA-CD/CD Text X / No
In Outputs
- Analog L&R Out Balanced:1, Unbalanced: 1
- Headphone Out No
- Digital Out Coax: 1, Opt: 1
- Digital In No
- Other In/Out No
- External control External Clock Input (BNC): 1
- D-Bus Remote (RC-5) In/Out No / No
Specifications
- Format 1-Bit DSD
- Sampling Frequency 2.8224MHz
- Dynamic Range 114dB
- Frequency response 2Hz - 50kHz (-3dB)
- THD 0.00%
- Format 16-Bit Linear PCM
- Sampling Frequency 44.1kHz
- Dynamic Range 100dB
- Frequency response 2Hz - 20kHz
- THD 0.00%
General
- Color Gold
- Front Panel 3pces Aluminum
- Remote Control No Aluminum Top with Marantz Amp. Basic Control Function
- Power Requirement AC 120V 60Hz
- Power Consumption 26W
- Dimensions W x H x D (Inchs) 18”-1/8" x 5-7/16" x 16-13/16"
- Weight (lbs) 49.1
