主な機能／特長
- Number of Channels 7.2 Channels
- Audyssey Audyssey MultEQXT, DSX, Dynamic EQ, Dynamic Volume
- DTS DTS HD Master Audio, HD High Resolution, ES Discrete/Matrix, Neo:6, 96/24
- Dolby Dolby TrueHD, Digital, Digital Plus, Pro Logic IIz, EX
- DSD (SA-CD)/Neural ○ / －
- SRS －
- 電流帰還型回路 －
- Discrete Amplification ○
- 電源トランス EI Core
- Digital Signal Processing Analog Devices ADSP21487
- Video Off (Pure Direct) ○
- ソース・ダイレクト ○
- Chassis Full Size
- Variable X-over ○
- Video Up-conversion ○ (Analog Composite/Component Video to HDMI)
- Auto Calibration by MIC Audyssey MultEQXT (upgradeable to Pro by Installer)
- Satellite Radio Ready －
- AM/FM チューナー FM Tuner Only
- Bass Redirection ○
- Lip-sync (digital audio delay) ○
- Software Upgradable ○ (via Internet)
In Outputs
- HDMI In 6 (including front HDMI input)
- Component In 2
- S-Video In －
- Composite In 4
- HDMI Out 2
- Component Out 2
- S-Video Out －
- Composite Out 2
- Analog L&R In 7
- Analog L&R Out 1
- Digital Optical In 2
- Digital Coaxial In 2
- Digital Optical Out －
- Digital Coaxial Out －
- その他
- Pre-Amplifier Out 7.2
- Main Amplifier In －
- Multi-Channel In 7.1
- Multi-Room Audio Out Zone 2 Preout (Variable)
- Multi-Room Video Out －
- Multi-Room Speaker Out ○ (Selectable)
- Speaker A/B －
- Networking AirPlay, DLNA 1.5 certified Audio/Photo Streaming, Internet Radio, Streaming service capability (Pandora/SiriusXM/flickr and Spotify)
- SetUp Wizard ○ (Setup Assistant)
- External control RS-232C / IP
- DC Triggers 1
- D-Bus Remote (RC-5) In/Out ○
- Flasher In/IR Receiver In/Emitter out 1 / － / －
- Front Panel A/V Inputs Front HDMI, USB and A/V inputs
- ヘッドフォン出力 1
- AC Outlets (Switched/Unswitched) － / －
主な仕様
- Power Output 110W (20Hz - 20kHz, 0.08% THD, 2ch driven)
- S/N Ratio 100dB
- Freq. Response (Analog In) 10Hz - 100kHz (+/- 3 dB)
- Freq. Response (Dig In) －
- Frequency Range 87.5 No 107.9MHz
- S/N Ratio (Mono/Stereo) 70/67 dB
- Frequency Range －
- S/N Ratio －
- Video Freq. Response (Component) 5Hz - 60MHz
- Video Freq. Response (Composit, S-Video) 5Hz - 10MHz
- Signal to Noise
一般
- Color Black
- Front Panel Aluminum / Glass-resinforced resin
- 付属リモコン Simple
- Power Requirement AC120V 60Hz
- 消費電力 650W (Standby 0.2W)
- Dimensions W x H x D (Inchs) 17-3/8 x 6-11/32 x 15.31
