主な機能／特長
- Number of Channels 7 ch Amp. 7.1 ch Processing
- THX －
- DTS HD Master & High Res. Audio/ES/96/24/ Discrete & Matrix6.1/ Neo:6
- Dolby True HD/Digital Plus&EX/ Pro Logic IIx
- DSD (SA-CD)/Neural － / －
- SRS －
- 電流帰還型回路 －
- Discrete Amplification ○
- 電源トランス EI
- D/Aコンバーター 192kHz/24-Bit
- Digital Signal Processing 32-Bit
- Video Off (Pure Direct) －
- ソース・ダイレクト ○
- Chassis Slimline, Steel
- Variable X-over ○
- Video Up-conversion Video/Component to HDMI
- Auto Calibration by MIC M.R.A.C.(Marantz Room Accoustic Caliblation)
- Satellite Radio Ready －
- AM/FM チューナー 1
- Bass Redirection －
- Lip-sync (digital audio delay) up to 200msec
- Software Upgradable by Marantz Service
In Outputs
- HDMI In 4
- Component In 3
- S-Video In 0
- Composite In 3
- HDMI Out 1
- Component Out 1 (Monitor Out)
- S-Video Out 0
- Composite Out 2 (incl. Monitor Out)
- Analog L&R In 6 (incl. Front mini jack input)
- Analog L&R Out 1
- Digital Optical In 2
- Digital Coaxial In 2
- Digital Optical Out 0
- Digital Coaxial Out 0
- その他 －
- Pre-Amplifier Out Sub Woofer x1
- Main Amplifier In 0
- Multi-Channel In 0
- Multi-Room Audio Out －
- Multi-Room Video Out －
- Multi-Room Speaker Out －
- Speaker A/B －
- Networking －
- External control －
- DC Triggers －
- D-Bus Remote (RC-5) In/Out 1 / 1
- Flasher In/IR Receiver In/Emitter out 0/0/0
- Front Panel A/V Inputs 3.5mm mini jcak (L/R) for Portable Audio Player etc.
- ヘッドフォン出力 1
- AC Outlets (Switched/Unswitched) － / －
主な仕様
- Power Output 50W (20Hz - 20kHz, 0.08% THD, 2ch driven) x7
- S/N Ratio 100dB
- Freq. Response (Analog In) 8Hz - 100kHz (+/- 3 dB)
- Freq. Response (Dig In) 8Hz - 45kHz (+/- 3 dB, 96kHz PCM signal source)
- Frequency Range 87.5 - 108MHz
- S/N Ratio (Mono/Stereo) 75/70 dB
- Frequency Range 530 - 1710kHz
- S/N Ratio 40dB
- Video Freq. Response (Component) 5Hz - 80MHz (-1dB)
- Video Freq. Response (Composit, S-Video) 5Hz - 8MHz (-1dB)
- Signal to Noise 60dB
一般
- Color Black
- Front Panel Aluminum/Glass-resinforced resin
- 付属リモコン Glow key, Precode
- Power Requirement AC120V 60Hz
- 消費電力 250W (Standby 0.5W)
- Dimensions W x H x D (Inchs) 17-3/8 x 4-3/16 x 14-1/2
