Multichannel Surround
- Compressed audio Enhancer: MDAX / MDAX2 No / Yes
- DTS HD Master / DTS 5.1 / DTS ES / DTS 96/24 Yes / Yes / Yes / Yes
- Dolby Digital Plus / Dolby TrueHD / Dolby Digital EX / DPL IIz Yes / Yes / Yes / Yes
- Audyssey DSX Yes
- Dolby Virtual Speaker / Neural Surround Yes / Yes
- HT-EQ / Re-EQ Yes / No
Sound Enhancements
- Current Feedback Topology Yes
- Hyper Dynamic Amplifier Modules (HDAM) Yes
- Pure Direct Yes
- Power Transformer: Toroidal / EI No / Yes
- High Grade Audio Components Yes
- Chassis: Copper plated / Metal Yes / No
Network
- DLNA Certified Yes (v1.5)
- UPnP Certified Yes
- Network Audio: MP3 / WAV / AAC / FLAC / WMA Yes / Yes / Yes / Yes (HD) / Yes
- Network static video (JPEG) Yes
- Internet Radio: direct / external media player Yes / Yes
- Ethernet Yes (with 4 port 10/100 MBit switch)
- IP Control Yes
- Apple APP control by iPhone/iPod touch Yes
- Spotify* Yes (not available in all countries)
- AirPlay Music Streaming Yes
Others
- Auto Speaker Setup by Microphone Audyssey MultEQ XT32 (PRO)
- Audyssey Dynamic EQ / Dynamic Volume Yes / Yes
- Video Conversion > HDMI
- Interlace / progressive conversion Yes
- Analogue to HDMI scaling > 4k
- HDMI to HDMI scaling Yes
- Videoprocessing Yes
- Picture adjust / Noise reduction Yes / Yes
- HDMI pass-through on stand-by Yes
- Deep Color pass through Yes
- 3D Video Pass-Through Yes
- Audio Return Channel Yes
- CEC Yes
- Front panel cursor control Yes
- On Screen Display: GUI / OSD No / Yes
- Front Flap Yes
Inputs Outputs
- Composite In / Out 4/3
- Component In / Out 3/2
- HDMI In / Out 7/3
- Balanced In / Out 2 / 11.2ch
- Digital Optical In / Out 2 / 0
- Phono (MM) In Yes
- Digital Coaxial In / Out 2 / 0
- Multichannel Pre Out / Main In 11.2ch / No
- Subwoofer Out 2
- 7.1 multichannel input Yes
- M-XPort for RX101 Yes
- Marantz Remote Bus Yes
- IR Flasher In Yes
- Network: (IP-control / update) Yes / Yes
- RS232C (control / update) Yes / Yes
- DC Triggers 2
- Analogue In / Out 8/2
- Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB Yes / Yes / No / Yes / Yes
- Height speaker terminal Yes (pre-out)
- USB Audio / Made for iPod / Works with iPhone Yes / Yes / Yes
Specifications
- Audio Signal to Noise Ratio 102dB
- FM Tuner Yes
General
- Available Colors: Gold / Silver / Black / Silver-Gold No / No / Yes / No
- Metal Front Panel Yes
- System Remote Control RC019SR
- Pre-Programmed / Learnable / LCD Display Yes / Yes / Yes
- Power Consumption in W 90
- Standby Consumption in W 0.2
- Detachable Power Cable Yes
- Maximum Dimensions (W x D x H) in mm 440 x 185 x 390
- Weight in kg 13.9
