Features
- Disc Capacity 1
- CD Compatibility: CD / CD-R/RW / SA-CD / WMA / MP3 / AAC Yes / Yes / No / Yes / Yes / Yes
- CD-Text / SA-CD Text / ID3 Tag / WMA Meta Tag / AAC Meta data Yes / No / Yes / Yes / Yes
- iPod / iPhone compatible USB input Yes
- HDAM version HDAM+HDAM SA2
- Power Transformer: Toroidal / El No / Yes
- High Grade Audio Components Yes
- Customised Components Yes
- Symmetric circuit layout Yes
- Extra metal plate for chassis strengthing Yes
- Digital out off / Audio EX Mode Yes / Yes
- Headphone: Standard / Buffer / Current feedback No / Yes (HDAM-SA2) / No
Others
- Separated rectifier circuit for analogue and digital circuitry Yes
- System block shielding: Copper / metal / none No / No / Yes
- Display: Dimmer / Off Yes / Yes
Playback
- Program Play (CD) 25
- Auto Music Scan (AMS) Yes
- Repeat Yes
- Random Play Yes
- Quick Replay Yes
Inputs Outputs
- Analogue Out (Cinch) 2ch
- Digital Optical In / Out No / 1
- Digital Coaxial In / Out No / 1
- Gold Plated Cinch Yes
- USB Audio (Front ) / Made for iPod / Works with iPhone Yes / Yes / Yes
- D-Bus Yes
- Headphone Out Yes
- Headphone Volume Control Yes
Specifications
- Mechanism CJDKT690
- D/A Conversion Multi-bit, Delta-Sigma
- DAC IC CS4398
- Digital Filter CS4398
- Noise Shaper CS4398
- Low Pass Filter stage HDAM
- Output Buffer HDAM-SA2
- Headphone amp HDAM-SA2 + Buffer
- Frequency response 2 Hz - 20 kHz
- Dynamic Range 100 dB
- Signal to Noise Ratio 110 dB
- Total Harmonic Distortion 0.00%
- Signal to Noise Ratio 98 dB
General
- Available Colors: Gold / Silver / Black / Silver-Gold No / No / Yes / Yes
- Metal Front Panel Yes
- Remote Control RC001PMCD
- Power Consumption in W 32
- Standby Consumption in W 0.3
- Auto Power off Yes
- Detachable Power Cable Yes
- Maximum Dimensions (W x D x H) in mm 440 x 105 x 338
- Weight in kg 6.6
