Features
- Disc Capacity 1
- CD Compatibility: CD / CD-R/RW / SA-CD / WMA / MP3 / AAC Yes / Yes / Yes / Yes / Yes / No
- iPod / iPhone compatible USB input Yes
- HDAM version SA2
- Power Transformer: Toroidal / El Yes / No
- High Grade Audio Components Yes
- Customised Components Yes
- Symmetric circuit layout Yes
- Copper Plated Chassis Yes
- Extra metal plate for chassis strengthing Yes
- Digital out off / Audio EX Mode Yes / No
- Headphone: Standard / Buffer / Current feedback No / No / Yes
Others
- Relay muting Yes
- Selectable filter: CD / SA-CD Yes / Yes
- Noise shaper (on / off) Yes
- DC filter (on / off) Yes
- Zero Impedance Matching joint copper Yes
- Separated rectifier circuit for analogue and digital circuitry Yes
- System block shielding: Copper / metal / none Yes / No / No
- Display: Dimmer / Off No / Yes
- Low noise LCD display Yes
Playback
- Program Play (CD) 20
- Auto Music Scan (AMS) Yes
- Repeat Yes
- Random Play Yes
- Start Sound Mode for SA-CD Yes
Inputs Outputs
- Analogue Out (Cinch) 2ch
- Balanced Out Yes
- Digital Optical In / Out Yes / Yes
- Digital Coaxial In / Out Yes / Yes
- USB Audio (Front ) / Made for iPod / Works with iPhone Yes
- USB type B input for PC (rear) Yes
- D-Bus Yes
- Headphone Out Yes
- Headphone Volume Control Yes
Specifications
- Mechanism SACDM-2
- Decoder CXD1885Q
- D/A Conversion DSD1792
- Digital Filter DSP (Marantz)
- Noise Shaper DSP (Marantz)
- Low Pass Filter stage HDAM
- Output Buffer HDAM + HDAM SA2
- Headphone amp HDAM
- Frequency Response (Cust.) 2 Hz - 50 kHz
- Dynamic Range (SA) 114 dB
- Signal to Noise Ratio (SA) 109 dB
- Total Harmonic Distortion (SA) 0.00%
- Channel Separation (SA) 105 dB
- Frequency response 2 Hz - 20 kHz
- Dynamic Range 100 dB
- Signal to Noise Ratio 110 dB
- Total Harmonic Distortion 0.00%
- Signal to Noise Ratio 100 dB
General
- Available Colors: Gold / Silver / Black / Silver-Gold Yes / No / Yes / No
- Metal Front Panel Yes
- Remote Control RC001PMSA
- Power Consumption in W 26
- Standby Consumption in W 0.3
- Detachable Power Cable Yes
- Maximum Dimensions (W x D x H) in mm 440 x 127 x 415
- Weight in kg 16.5
